Explore the great outdoors in all weather and all terrain with an Imperial Outdoors XploreRV toy hauler or travel trailer! It takes off-grid RVing to another level with cold weather versatility and at-home comforts, as well as the rugged capabilities of an off-road camper.



This beast is built to exceed the boundaries of a traditional RV and will roam anywhere others won't go with an off-road reinforced, coated steel frame and an obstruction free under carriage. The cold weather LP furnace will keep you comfortable down to -40 degrees Fahrenheit, and the D-ring recovery points help keep everything locked in place as you travel. You will also enjoy a full kitchen to cook in and a full bathroom with a dry flush toilet so you don't have to worry about a black tank when you're off-grid.



Make an Imperial Outdoors XploreRV toy hauler or travel trailer your mobile lodge or mountaintop adventure!

  • Specifications

    Sleeps 3
    Length 23 ft 4 in
    Ext Width 7 ft 9 in
    Ext Height 10 ft
    Int Height 6 ft 4 in
    Hitch Weight 425 lbs
    Gross Weight 8820 lbs
    Dry Weight 5370 lbs
    Cargo Weight 3450 lbs
    Fresh Water Capacity 30 gals
    Grey Water Capacity 30 gals
    Tire Size R15
    Furnace BTU 18000 btu
    Available Beds Full
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Number of Awnings 1
    Axle Weight 5000 lbs
    LP Tank Capacity 20 lbs
    Water Heater Type On Demand
    AC BTU 13500 btu
    TV Info LCD TV
    Awning Info Full Length
    Axle Count 2
    Number of LP Tanks 2
    Shower Type Radius

    Similar Floorplans

  • XploreRV X145

    XploreRV X145 Floorplan Image

    Imperial Outdoors XploreRV X145 highlights: Full Rear Bath Overhead Storage ... more about XploreRV X145

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 3
    Length 21 ft 7 in
    Ext Width 7 ft 7 in
    Ext Height 9 ft 9 in
    Int Height 6 ft 3 in
    Gross Weight 6172 lbs
    Fresh Water Capacity 60 gals
    Grey Water Capacity 60 gals
    Tire Size 265/75R16
    Furnace BTU 14300 btu
    Available Beds RV Full
    Refrigerator Size 3 cu ft
    Number of Awnings 1
    Axle Weight 6172 lbs
    LP Tank Capacity 20 lbs
    AC BTU 6824 btu
    Awning Info 22' 6" Batwing Style
    Number of LP Tanks 2
    Shower Type Standard

    Similar Floorplans

  • XploreRV X195

    XploreRV X195 Floorplan Image

    Imperial Outdoors XploreRV travel trailer X195 highlights: Accessory Mounts ... more about XploreRV X195

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 3
    Length 23 ft 4 in
    Ext Width 7 ft 7 in
    Ext Height 9 ft 9 in
    Int Height 6 ft 3 in
    Gross Weight 9920 lbs
    Fresh Water Capacity 60 gals
    Grey Water Capacity 60 gals
    Tire Size 265/75R16
    Furnace BTU 14300 btu
    Available Beds RV Full
    Refrigerator Size 6.9 cu ft
    Number of Awnings 1
    Axle Weight 9920 lbs
    LP Tank Capacity 20 lbs
    AC BTU 6824 btu
    Awning Info 22' 6" Batwing Style
    Number of LP Tanks 2
    Shower Type Standard

    Similar Floorplans

XploreRV Features:

Standard Features (2023)



***PLEASE NOTE: Features and Options separated by type below:

---------------------------------------------------

TRAVEL TRAILERS

Standard Features (Model Specific)

  • Off-road reinforced, coated steel frame
  • Obstruction Free Under Carriage
  • (all components above bottom of frame rail)
  • 2in Receiver Hitch for accessories (X22)
  • D-Ring recovery points
  • CRANE NOBLE® Sheet Glass Seamless Exterior Sidewalls (X22)
  • Innovative aluminum stud exterior wall construction (X22)
  • 1pc, fully insulated composite floor and fully walkable composite roof
  • Twin 20lb LP Fuel Tanks
  • Cold Weather LP Furnace
  • Low-profile Roof-Mounted A/C (X22)
  • Low-profile, high efficiency 12V(DC) Roof-Mounted A/C
  • LCD TV (X22)
  • Bluetooth Speaker
  • Full Kitchen w/Range, cooktop, full size refrigerator and kitchen sink
  • Full Bathroom w/shower and dry flush toilet (no black water tank to deal with in the back-country)
  • Upgraded 60 gallon fresh & 60 gallon grey water tanks (X145, X195)
  • Solid Surface Countertops (X22)
  • Convertible Dinette
  • Full Size Bed (RV Full) w/bedding
  • LED interior & exterior lighting
  • Exterior LED Perimeter Lighting
  • Off-Road Rock Lighting
  • Conveniently placed 120V outlets & USB charging ports
  • Roof-mounted MaxxAir ventilation system
  • Full Length Awning (X22)
  • Batwing Awning (X145, X195)
  • Exterior Pass-Through Storage
  • Exterior 120V Power Outlet
  • RVIA Certified

Xtreme Package (Standard Upgrades)

  • Hydraulic Ride Adjustment (12” Ground Clearance Road Height / 20” GC Off-Road Height) (X22)
  • 33 x 10.5 R15 Off Road Tires (X22)
  • Front Rubber Rock Guard (X22)
  • Dual full size spare tires mounted to rear swing-away carriers (X22)
  • Cruisemaster® ATX independent suspension (w/air bags, disc brakes, & parking brake) (X145, X195)
  • 265/75 R16 Off Road Tires (X145, X195)
  • Front Mounted Utility Box with LP & Generator Storage (generator not included) (X145, X195)
  • On-board air compressor
  • Custom Roof rack (w/3 cross-members)
  • Heavy Duty Ladder
  • Lock+Roll Off-Road Hitch (X22)
  • Cruisemaster Articulating Hitch (X145, X195)
  • Thermal Acrylic Windows
  • Dual 100ah Lithium Batteries (X22)
  • 360ah Lithium Battery (STAGE 1) (X145, X195)
  • Heated/Insulated Water Storage Tanks
  • On-demand hot water (X22)
  • 200W Roof Mounted Solar System (X22)
  • 240W Roof Mounted Solar System (STATE 1) (X145, X195)
  • MPPT Solar Control & Battery Monitor
  • Back-up Camera Prep
  • Outdoor Shower (X22)
  • Outdoor Shower hookup (X145, X195)
  • ARK Heavy Duty Rolling Tongue Jack & Leveling Jacks (X145, X195)
  • Customizable Rear Accessory Options (X145, X195)

Package Options

Blizzard Package (B) (X22)

  • INCLUDES XTREME PACKAGE
  • Twin 30lb LP Fuel Tanks
  • Roof Rack Utility Basket
  • Roof Mounted Ski Rack
  • LP Tank Heater

Wilderness Package (W) (X22)

  • INCLUDES XTREME PACKAGE
  • Hi-Lift Jack
  • Rotopax Fuel Container
  • Rear Spare-Tire Mounted Utility Basket (2 total)
  • Roof-Top Utility Basket

Wilderness Max Package (M) (X22)

  • INCLUDES XTREME PACKAGE
  • Hi-Lift Jack
  • Rotopax Fuel Container
  • Rear Spare-Tire Mounted Utility Basket (2 total)
  • Imperial Premium Rooftop Tent

Off Grid Max (+) (X22)

  • QUAD 120ah Lithium Batteries (480ah)
  • 2000W Inverter & Monitor Panel
  • Upgraded 760W Roof Mounted Solar System

Customizable Options

Power Storage

  • STAGE 2 - 720ah: (2) 360Ah Lithium Batteries (X145, X195)
  • STAGE 3 - 108Ah: (3) 360Ah Lithium Batteries (X195)

Solar Output

  • STAGE 2 - 740W: (7) Glass Solar Panels (X145, X195)
  • STAGE 3 - 1240W: (11) Glass Solar Panels (X195)

Accessory Options

Rear

  • (unit accommodates 2 rear accessory mounting locations + hi-lift jack mounts)
  • Spare Tire Mount w/Full Size Spare
  • Jerry Can Mount (fits standard NATO Jerry Cans - not included)
  • Rear Utility Box
  • Auxiliary Grid Panels (mounts to Front or Rear Utility Box)
  • Accessory Grid Panel (mounts to rear accessory bracket)
  • Hi-Lift Jack Mount (Hi-Lift Jack not included)

Front

  • Traction Board Mount
  • Auxiliary Grid Panels (mounts to front or rear utility box)

--------------------------------------------------

TOY HAULER TRAVEL TRAILER

Standard

  • Off-road reinforced, coated steel frame
  • Obstruction Free Under Carriage (all components above bottom of frame rail)
  • 2in Receiver Hitch for accessories
  • D-Ring recovery points
  • CRANE NOBLE® Sheet Glass Seamless Exterior Sidewalls
  • Innovative aluminum stud exterior wall construction
  • 1pc, fully insulated composite floor and fully walkable composite roof
  • Twin 20lb LP Fuel Tanks
  • Cold Weather LP Furnace
  • Low-profile Roof-Mounted A/C
  • LCD TV
  • Bluetooth Speaker
  • Full Kitchen w/Range, cooktop, full size refrigerator and kitchen sink
  • Full Bathroom w/shower and dry flush toilet (no black water tank to deal with in the back-country)
  • Rear Fold-Away Dinette
  • Full Size Electric Bed Lift
  • LED interior & exterior lighting
  • Exterior LED Perimeter Lighting
  • Off-Road Rock Lighting
  • Conveniently placed 120V outlets & USB charging ports
  • Roof-mounted MaxxAir ventilation system
  • Full Length Awning
  • 1000lb easy-lift ramp door
  • Floor mounted Tie downs
  • Exterior 120V Power Outlet
  • RVIA Certified

Xtreme Package (Standard Upgrades)

  • Hydraulic Ride Adjustment (12” Ground Clearance Road Height / 20” GC Off-Road Height)
  • 33x10.5 R15 Off Road Tires
  • Front Rubber Rock Guard
  • Dual full size spare tires mounted to rear swing-away carriers.
  • On-board air compressor
  • Custom Roof rack (w/3 cross-members)
  • Heavy Duty Ladder
  • Lock+Roll Off-Road Hitch
  • Thermal Acrylic Windows
  • Ramp Door Screen
  • Heated/Insulated Water Storage Tanks
  • On-demand hot water
  • Roof Mounted Solar System
  • Back-up Camera Prep
  • Outdoor Shower

Package Options

Blizzard Package (B)

  • INCLUDES XTREME PACKAGE
  • Twin 30lb LP Fuel Tanks
  • Ramp Door Thermal Blanket
  • Roof Rack Utility Basket
  • Upgraded Cold Weather LP Furnace
  • Roof Mounted Ski Rack
  • LP Tank Heater

Wilderness Package (W)

  • INCLUDES XTREME PACKAGE
  • Hi-Lift Jack
  • Rotopax Fuel Container
  • Rear Spare-Tire Mounted Utility Basket (2 total)
  • Roof-Top Utility Basket

Wilderness Max Package (M)

  • INCLUDES XTREME PACKAGE
  • Hi-Lift Jack
  • 2 Rotopax Fuel Containers
  • Rear Spare-Tire Mounted Utility Basket (2 total)
  • Imperial Premium Rooftop Tent

Off Grid Max (+)

  • DUAL 120ah Lithium Batteries (240ah)
  • 2000W Inverter & Monitor Panel
  • Upgraded 390W Roof Mounted Solar System

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions.  See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.

Manu-Facts:

Imperial Outdoors

Nelson Industries started out as a custom finishing company over 10 years ago. Since the beginning, we've been providing some of the best interior layouts in the fish house industry. All of our interiors are fully finished in quality tongue and groove and appointed with top quality accessories and electronics. We pay special attention to the functionality and usability of our product, not just the aesthetic. Our employees are outdoor enthusiasts and we field test our own products regularly to ensure we're providing the best user experience and quality possible. We are fortunate to have low employee turnover, which translates to knowledgeable, skilled employees that are passionate about what we do.



Taking our acquired knowledge over the past decade, we've created a product that ranks a step ahead of the competition. The Imperial fish house is a new offering by Nelson Industries that reflects all of our combined experience and knowledge in a luxury fish house. With sturdier construction, better insulation, and strong focus on weight reduction, Imperial is built from the ground up with owner satisfaction in mind.



We're taking this concept and applying it to the RV industry as well. We also have developed a true 4-season, off-road capable unit specifically for those looking to take their RV on an outdoor adventure. The Imperial XploreRV combines the same construction and insulation methods that keep ice-fisherman warm in -40°F temperatures, with a reinforced chassis that boasts 20+ inches of ground clearance and large, off-road tires. XploreRV eliminates the "off-season" and will make you rethink your stance on winter camping!



We stand by our craftsmanship by offering industry standard warranties on all of our products. It is important to us that our customers are happy with their investment. We pride ourselves on our quality and customer service.
